| Model No. |
L04 |
| Product materials |
Aluminum Alloy |
| Color |
Black/Sliver/Charcoal |
| Lock body |
60-70mm |
| Unlock Method |
Fingerprint / Passcode / Key / App / IC card |
| User capabilities |
10 Admin
Fingerprint (≤50 pieces)
IC card (≤50 pieces)
Passcode (≤50 pieces) |
| Power Supply |
2500 mAh Lithium battery |
| Operating Voltage |
6.0 ~ 8.2V
|
| Alarm Voltage |
5V |
| Deep Sleep Power Consumption |
≤30uA |
| Static Power Consumption |
80 μAh |
| Dynamic Power Consumption |
≤250mA |
| APP |
TUYA |
| Size |
Front: 64(L) × 144(H) × 17(W) mm
Rear: 73(L) × 161(H) × 48(W) mm |
| Network |
WIFI |
| Door Type |
Wooden door / Office door / Hotel door |
| Door Thickness |
35–65 mm |
| Emergency Situations |
Emergency charging port (Type-C USB) |
| False Recognition Rate |
<0.001% |
| False Reject Rate |
<0.1% |
| Working Temperature |
−25 ~ +65 ℃ |
| Storage Temperature |
−40 ~ +85 ℃ |
| Humidity Requirements |
20% ~ 90% RH
|
| Documents |
Instruction.PDF |
