| Model No. |
D01 |
| Product materials |
Aluminum Alloy + Satinless Steel |
| Color |
Matte Black, SN |
| Lock body |
60–70mm Latch |
| Unlock Method |
Fingerprint / Key / App |
| User capabilities |
Fingerprint（the first 3 are administrators and the back 17 are rugular users） |
| Power Supply |
3.7V / 400mAh |
| Operating Voltage |
3.3–4.2V |
| Alarm Voltage |
3.5±0.1V |
| Deep Sleep Power Consumption |
≤30 uA |
| Static Power Consumption |
≤50 uA |
| Dynamic Power Consumption |
≤200 mA |
| APP |
TUYA |
| Size |
390 × 75 mm |
| Network |
Bluetooth |
| Door Type |
Wooden door / Office door / Extremely Narrow door / Ecological door |
| Door Thickness |
35–55 mm |
| Emergency Situations |
Emergency charging port |
| False Recognition Rate |
<0.001% |
| Working Temperature |
−25 ~ +70 ℃ |
| Storage Temperature |
−40 ~ +85 ℃ |
| Humidity Requirements |
<93% RH |
| Documents |
U-Bolt Pro WiFi Installation and User Guide, V2.4
Ultraloq U-Bolt Series Drill Template V1.6
